Large Diameter Internal Gears are highly specialized mechanical transmission components featuring teeth cut into the inside diameter of a cylinder or ring. Compared to external gears, internal gears allow for a significantly more compact design with a shorter center distance between mating gears, making them the ultimate solution for space-constrained, high-torque industrial applications.
As an essential component for heavy-duty drive systems, our precision-machined internal gears are widely utilized across demanding B2B engineering sectors:
Planetary Gear Systems: Functioning as the outer ring gear in planetary gearboxes to provide high reduction ratios in compact spaces.
Heavy Machinery: Crucial for the slewing drives and rotary tables of excavators, cranes, and large-scale mining equipment.
Wind Turbines: Providing reliable, high-torque power transmission within renewable energy pitch and yaw drive mechanisms.
Industrial Robotics & Automation: Ensuring highly accurate, low-backlash articulation for heavy-duty robotic arms and automated positioning stages.
Superior Load Capacity & Smoothness: The internal tooth design ensures a higher contact ratio (more teeth engaged simultaneously) compared to external gears, delivering vastly improved torque capacity, smoother operation, and reduced vibration.
Space-Saving Geometry: Allows the mating pinion gear to operate within the internal gear’s diameter, creating an incredibly compact mechanical footprint ideal for integrated machinery.
Precision CNC Manufacturing: Machined to strict AGMA/DIN tolerance standards using advanced CNC gear shaping, broaching, and milling techniques to ensure perfect pitch accuracy and true concentricity.
Heavy-Duty Metallurgy: Forged from premium alloy steels and subjected to precise heat treatments (such as nitriding or carburizing) to achieve exceptional surface hardness, wear resistance, and long-term fatigue strength.
Welcome to Xinmingliang Technology Co., Ltd. (XML Tech). Backed by over a decade of intensive professional experience in the CNC hardware industry, we are a dedicated source manufacturing facility committed to delivering ultra-precision component processing services to the global market.
Dedicated Parts Manufacturing: We are professional CNC machining specialists focused strictly on manufacturing high-quality parts. We ensure every large internal gear is machined to perfectly integrate into your specific equipment design.
True Turnkey Source Factory: Source your precision gears directly from our production workshop. By eliminating trading company markups, we offer highly competitive direct-factory pricing to maximize your B2B profit margins.
All-Around Hardware Processing Capabilities: We are an all-around custom hardware manufacturer. Our multi-axis CNC expertise covers all material categories, including high-strength alloy steels, aluminum, pure copper, brass, titanium alloys, and industrial plastics.
Advanced Machining & Strict QC: Equipped with state-of-the-art CNC shaping and turning centers, our technical team handles high-complexity geometry with ease. Every machined gear undergoes severe dimensional audits and profile inspections using CMM before shipping.
