Custom HDPE CNC Machining Services | XML Precision Hardware Manufacturing

Searching for chemically resistant, durable, and food-safe plastic components? XML provides expert HDPE (High-Density Polyethylene) CNC machining services. Valued for its zero moisture absorption, excellent impact strength, and low coefficient of friction, HDPE is the material of choice for food processing automation, medical trays, marine equipment, and chemical fluid handling. From custom prototyping to high-volume production, XML delivers reliable, all-around manufacturing solutions. Get a free quote today!

Why Choose HDPE for CNC Machining?

HDPE (High-Density Polyethylene) is one of the most versatile and durable thermoplastics on the market. While it is softer and more flexible than Acetal (Delrin) or ABS, its ability to withstand extreme environments, harsh chemicals, and heavy impacts makes it completely irreplaceable in many industries.

Whether you are designing sterile medical equipment or heavy-duty chemical tanks, this material delivers:

Supreme Chemical Resistance: Practically immune to most acids, bases, alcohols, and corrosive industrial chemicals.
FDA Compliant & Food Safe: Non-toxic, non-leaching, and highly resistant to bacteria, making it the industry standard for food and beverage processing.
Zero Moisture Absorption: Will not swell, degrade, or change dimensions when submerged in water, making it perfect for marine and fluid applications.
High Impact & Wear Resistance: Acts as a fantastic wear surface with a naturally low coefficient of friction, capable of taking massive hits without cracking.

As your expert manufacturing partner, XML utilizes advanced thermal management and high-speed CNC routing to machine HDPE cleanly without melting or warping.

HDPE Technical Specifications & Machining Parameters

Mechanical & Thermal Properties	Metric Value	Imperial Value	Test Standard
Density (Specific Gravity)	0.94 – 0.96 g/cm³ (Floats in water)	0.034 lbs/in³	ASTM D792
Tensile Strength (Yield)	20 – 30 MPa	2,900 – 4,350 psi	ASTM D638
Flexural Modulus	1.0 – 1.5 GPa	145,000 – 215,000 psi	ASTM D790
Water Absorption (24 hrs)	< 0.01% (Effectively Zero)	< 0.01%	ASTM D570
Hardness (Shore D)	D65 – D70 (Relatively soft)	D65 – D70	ASTM D2240
Max Continuous Temp	80°C – 90°C	176°F – 194°F	UL 746B
Chemical Resistance	Outstanding (Resists acids/alkalis)	Outstanding	–

Machining Parameters	Technical Specifications
Standard Tolerances	±0.1 mm to ±0.2 mm (Due to natural material flexibility)
Minimum Wall Thickness	≥ 1.5 mm (0.060″) recommended to prevent flexing
As-Machined Surface Finish	Ra 1.6 – Ra 3.2 μm (Smooth, slightly waxy finish)
Cutting Strategy	Extremely high feed rates and spindle speeds to prevent heat build-up and melting
Tooling Specifics	Razor-sharp, single-flute solid carbide routers designed for soft plastics
Thermal Management	Active air blast or mist cooling to mitigate thermal expansion during cutting
Post-Processing	Typically used “as-machined.” Cannot be easily glued or painted due to low surface energy.
Supported Operations	3-Axis & 5-Axis CNC Milling, CNC Routing (for large panels), CNC Turning

Extensive Industry Applications of HDPE Parts

Aerospace

XML Precision engineers rugged HDPE solutions for challenging marine and ground aerospace environments. We possess the capabilities to machine durable wear pads, dock bumpers, and lightweight chemical containers, leveraging HDPE’s inherent high-impact strength and salt water corrosion resistance.

Medical Devices

Our FDA-compliant HDPE parts are designed for sanitization, with zero moisture absorption and extreme chemical resistance. XML Precision manufactures custom medical sterilization trays, orthopedic component housing, and laboratory equipment bases for critical, clean applications.

Robotics & Automation

We process food-safe HDPE into the backbone components for high-speed automated systems. This includes precise conveyor guide rails, low-friction packaging wear strips, and custom chutes, all designed to meet the strictest industry hygienic standards.

Automotive

In the automotive and heavy vehicle sectors, our precision-machined HDPE components deliver unmatched impact protection and durability. XML Precision creates tough skid plates, chemical tank flanges, and fluid distribution manifolds to ensure consistent performance in demanding conditions.
